Automatic Sensor Doors
Automatic sensor doors open and close automatically when they detect movement, providing quick, safe, and convenient access in busy spaces.
Key Features
- Doors open and close automatically using advanced motion sensors, ensuring smooth and effortless entry.
- Ideal for hospitals and public spaces, the contact-free mechanism helps reduce germ transmission.
- Opens only when needed, helping maintain indoor temperature and reducing heating/cooling load.
- Sleek glass panels and clean aesthetics enhance the overall look of any building.
- Available in sliding and swinging configurations with adjustable speed, sensitivity, and opening width.
Series:
Autosense
Model:
AMAS01
Technical Specifications
Parameter
specifications
Power supply
full range 100÷240 Vac | 50/60 Hz
power consumption
70 W
power consumption in stand-by
3 W
accessories power supply
24 Vdc = / 1 A max
maximum speed 1 door
0.8 m/s
maximum speed 2 doors
1.6 m/s
maximum load 1 door
150 kg
maximum load 2 doors
80 + 80 kg
type and frequency of use
continuous operation = 100%
operating temperature -15°C / +50°C
-15°C / +50°C
protection degree
IP20
data backup memory
USB flash drive
Series:
Autosense
Model:
AMAS02/AMS02i
Technical Specifications
Parameter
AMAS02
AMS02i
power supply
full range 100÷240 Vac | 50/60 Hz
full range 100÷240 Vac | 50/60 Hz
power consumption
70 W
70 W
power consumption in stand-by
3 W
3 W
accessories power supply
24 Vdc = / 1 A max
24 Vdc = / 1 A max
opening time
3÷12 s / 90°
5÷15 s / 90°
closing time
5÷12 s / 90°
6÷15 s / 90°
maximum torque
45 Nm
28 Nm opening | 18 Nm closing
operation type
motor-driven opening | motor-driven closing
motor-driven opening | spring closing
type and frequency of use
continuous operation = 100%
continuous operation = 100%
protection degree
IP31
IP31
data backup memory
USB flash drive
USB flash drive
