Series:
DoorDrift
Model:
AMPT100
Technical Specifications
Parameter
Specifications
Dimension
230*165*1050
Material
304 original brushed stainless steel, acrylic
Channel Width
Standard 450mm (<600mm can be customized)
Full Thickness of The Outer Box
0.8mm
Motor
24V DC brushless motor, low noise
Movement Structure
2-stage deceleration horizontal 3rd-generation movement
Mainboard
Brushless control system
Traffic Direction
One-way traffic/two-way traffic
Opening Signal
Dry contact signal
Life
≥6 million times
Infrared Quantity
Single-shot infrared
Applicable Temperature
-15~75 ℃ (add thermostat below this temperature)
Opening Mode
ID & IC card swiping and other reading head verification opening, infrared induction automatic opening, button opening, etc.
Protection Function
Electromechanical anti-collision, infrared anti-pinch, illegal intrusion infrared alarm
