Series:
EntrancePRO
Model:
AMSFB2000
Model overview:
Automates AMSFB2000 is a fully automatic swing gate barrier powered by a 24V brushless DC motor, supporting multiple access modes with advanced safety features like anti-collision, anti-pinch, and intrusion alarm.
Technical Specifications
Parameter
Specifications
Dimension
185mm*970*1200mm
Material
SS 304 Stainless steel + Acrylic
Passage Width
600-850mm (<570 can be customized)
Outer Box
1.0mm+1.2mm
Motor
24V brushless DC motor, low noise
Control Panel
Integrated brushless control system
Traffic Direction
One-way traffic/two-way traffic
Opening mode
Biometric identification, IDIC, remote control switch, etc
Opening signal
Dry contact signal, can be customized RS232 mode
Lifetime
≥6 million times
Traffic Speed
35-40 Peoples / Min.
Power
40-60w
Applicable temperature
-20~70 °C (below -15 °C plus thermostat)
Support
Indoor and outdoor use
