Series:
EntranceEase
Model:
AMT300S
Technical Specifications
Parameter
Specifications
Dimension
360*260*980
Material
304 original brushed stainless steel, acrylic
Channel Width
510mm
Thickness
The full thickness of the outer box is 1.0+3.0mm
Traffic Direction
One-way traffic/two-way traffic
Traffic Speed
25~30 people/min in normally open mode and 15~20 people/min in normally closed mode The actual traffic speed is different from the traffic environment and personnel
Opening mode
ID & IC card swiping and other reading head verification opening, button opening, etc.
Opening signal
Dry contact signal
Life
≥5 million times
Power
30-60W
Applicable temperature
-20~75 ℃ (add thermostat below this temperature)
Series:
EntranceEase
Model:
AMT300F
Model overview:
Turnstile gates are designed to regulate pedestrian movement by allowing one person to pass at a time. They provide secure, controlled access using mechanical or electronic operation, making them ideal for managing entry and exit in high-traffic and restricted areas.
Technical Specifications
Parameter
Specifications
Integration
Face/Finger/Card
Dimension
215x980x1200mm
Passage Width
510mm
Material
SS 304 Stainless steel + Acrylic
Traffic Direction
One-way traffic/two-way traffic
Traffic Speed
25-30 People / Min.
Life
≥5 million times
Power
30-60W
Operating Temperature
-20℃ ~70 ℃
Series:
EntranceEase
Model:
AMT300ST
Technical Specifications
Parameter
Specifications
Integration
Face/Finger/Card
Dimension
185x1200x981mm
Passage Width
510mm
Material
SS 304 Stainless steel + Acrylic
Traffic Direction
One-way traffic/two-way traffic
Traffic Speed
25-30 People / Min.
Life
≥5 million times
Power
30-60W
Operating Temperature
-20℃ ~70 ℃
